Intelligent Fast-Charging System
GSE O&M for DVS300 / 330 / 330 IP55 / 400 and MVS330/400
31504-03-0101 Webasto Charging Systems, Inc.19
4.3 – System Startup
The DVS is ready to be powered on once it has been properly installed (mechanically and electrically). The
system performs a lamp test when rst powered on. The display then shows the initial status window containing
the model number and software version. The system then sequences through two more status windows before
reaching the Charger Ready Connect Vehicle window (Figure 6). The windows for each charge port alternate
when initialization is complete.
NOTE
An arrow in the upper-left or -right corner of the window indicates which chan-
nel data currently are being displayed.
DVS 40kW 500 Amps
Version xx.xx.xx.xx
Station unavailable
Please see system stat
Conguring network
Starting power server
Charger ready
Connect vehicle
Figure 6 – Startup Windows
