Intelligent Fast-Charging System
GSE O&M for DVS300 / 330 / 330 IP55 / 400 and MVS330/400
31504-03-0101 Webasto Charging Systems, Inc.21
LED Label Color When Steadily Lit When Flashing
Equalize Green The battery is undergoing equalization. The equalization is scheduled.
Charge Completed Green The charge is completed and stopped. NA
80% Charged Green The battery SOC is > 80%. NA
Charging Amber The battery is connecting and charging. NA
Fault / Warning Red Fault (The charge is stopped.) Warning (Check the log.)
2. Stop Charging.
The DVS stops the charge and illuminates the Charge Completed LED once the battery has been fast-
charged to the SOC preset in the BMID. If an equalization is scheduled for this battery pack then the
Charge Completed LED will not be illuminated until the equalization has been completed. The operator
may stop charging at any time without waiting for the charge to be completed, by pressing the STOP
button.
A window indicates the method in which the charge was stopped and displays the data values just before
the end of charging (Figure 8) after a charge has been stopped by the operator or completed.
<Chg Completed 81%
62.2V 50.0A 55 °C
<Chg Stopped 62%
60.1V 500A 50 °C
OR
Figure 8 – Charge Completed / Stopped Windows
3. Disconnect the battery cables from the charger (power station).
NOTE If the operator disconnects the cables without pressing the STOP button then
the charger (power station) immediately will stop charging and prevent any
arcing or damage to either the charger (power station) or battery. It is strongly
recommended, however, that operators rst press the STOP button.
