Weber Summit 450 - Burner Assembly Removal; Manifold and Burner Slide-Out

15
10. Slide the burner assembly from each Heat Zone.
The left and right burners are connected by the
Crossover tube.
(1)
9. Pull the manifold(1) out of the burners.
GENERAL MAINTENANCE
Figure 13
Pull out of here
Crossover tube
Summit 450
Summit 650
