Weber Summit 470 - Grill Hardware and Assembly Steps; Hardware Components; Assembly Step 3: Frame and Doors; Assembly Steps 4-7: Component Installation

5
6
7
a
4
D
D
D
A
B
C
3
8
Hardware:
Wrench - 1
Bracket - 4
Silver Hex Bolt
(1/4-20x5/8In.)-4
Screw - 3
Plastic Plug - 3
The Weber Grill Out™ Handle Light has a “Tilt
Sensor”: Lid up - ON / Lid Closed - OFF. The
power button (a) activates or deactivates the “Tilt
Sensor.” For daytime use, deactivate the sensor
by pressing power button (a).
SeeOwner’sGuideforcomplete
retractablerotisserieinstructions.
Requires 3 “D” alkaline batteries (Included). Use alkaline batteries only. Do not mix old
and new batteries or different types of batteries (standard, alkaline or rechargeable).
9
+
+
AAA
+
+
AAA
+
+
AAA
Requires 3 “AAA” alkaline batteries
(not included)
SeeOwner’sManualforcompletegasinstructions.
2 -
10
4 -
