Weber Summit 650 - Page 15

15
10. Slide the burner assembly from each Heat Zone.
The left and right burners are connected by the
Crossover tube.
(1)
9. Pull the manifold(1) out of the burners.
GENERAL MAINTENANCE
Figure 13
Pull out of here
Crossover tube
Summit 450
Summit 650
