13
OFFICE 200 (DIRECTIONAL/PANEL) CELL SIGNAL BOOSTER
ENGLISH
______
Menu System
The Oce 200 takes about 5 seconds to boot up. Once boot up is complete, the home
screen will appear, showing the amplification and status of each port and band.
GREEN: A solid green light indicates that a band is operating correctly with maximum
allowable gain.
YELLOW: A solid yellow light indicates band gain reduction because of an oscillation
condition. Reposition antennas (increase separation between indoor and outdoor
antennas, and then reboot (turn the unit o & on) the Oce 200 to reactivate the band
and maximize performance. When adequate separation is achieved, the yellow lights
will return to green upon reboot. Note: when the light is yellow, the band is operational;
however, performance is reduced.
RED: A red light indicates a band has been shut down because of a severe oscillation
condition or repeated oscillation. Reposition antennas (increase separation between
indoor and outdoor antennas, and then reboot (turn the unit o & on) the Oce 200
to reactivate the band and maximize performance. When adequate separation is
achieved, the red light(s) will return to green upon reboot.
GRAY: Gray indicates band has been disabled.
Band Menu Color Desrciption
Start Up Screen
Home Screen
