4
CELL SIGNAL BOOSTER (DIRECTIONAL/PANEL) OFFICE 200
ENGLISH
______
Installation Diagram
Outside
Antenna
Booster
to power
Lightning Surge
Protector
Inside
Antenna
G
r
o
u
n
d
22 m Coax Cable
18 m Coax Cable
Troubleshooting section recommends increasing distance
further if needed.
18 METER HORIZONTAL OR 7 METER VERTICAL DISTANCE
