4
(ANTENNE DIRECTIONNELLE/PANNEAU) OFFICE 200
FRANÇAIS
AMPLIFICATEUR DE SIGNAL CELLULAIRE
______
Diagramme d’installation
Antenne
extérieure
Amplificateur
Dans la section Dépannage, on recommande d’augmenter
la distance, au besoin.
vers la source
d’alimentation
Limiteur de
surtension
Antenne
intérieure
M
i
s
e
à
l
a
t
e
r
r
e
Câble coaxial de 22 m
Câble coaxial de 18 m
DISTANCE DE 60PI À L’HORIZONTALE OU DE 25PI À LA VERTICALE
