Webster SC Series User Manual

SC BURNER MODEL CONFIGURATION
FIGURE A-2
SC12G -50-LMV51-M.25-M-MP-UL/CSD-1
BURNER SERIES
SC SC SERIES
HEAD SIZE (INCHES)
SC
8
10
12
12.3
13
13.8
14
15
15.8
16
18
20
24
FUELS
G Gas
C Gas/Oil
O Oil
BLOWER MOTOR
HORSEPOWER
20 2
25 2 1/2
30 3
50 5
75 7 1/2
100 10
150 15
200 20
250 25
300 30
400 40
FLAME SAFEGUARD
VENDOR DESIGNATION
M Mark AutoFlame - mini mark
Nexus Fireye
LMV51 Siemens
LMV52 Siemens
The above represents the common model designations. Contact the factory for other options and special applications.
Page 5 Model CongurationSC Manual
CODES AND
LISTINGS
UL
ULc
CSD-1
FM
IRI
NFPA-85
OIL SYSTEMS
Pressure Atomizing
MR Modulation By-Pass
MP Modulation Simplex
Air or Steam Atomization
MA Air Atomization
MS Steam atomizing
GAS TRAIN VENDOR
VGD Siemens
VGG Siemens
M Maxon
Blank
All Others
(ASCO) - (std)
GAS TRAIN SIZE
.15 1 1/2 inches
.20 2 inches
.25 2 1/2 inches
.30 3 inches
.40 4 inches
GAS SYSTEMS
M Modulation
