B. COMPONENT IDENTIFICATION
Page 8 IdenticationSC Manual
Control
Cabinet
Louver Box
This secion shows the different common components used in the SC burner line and should be helpful to identify
parts described elsewhere in this manual.
Oil Pressure Switch
Oil Pressure Gauge
Oil Lines
Air Pressure Switch
Pilot Gas
Regulator
Secondary Fuel
Mod Motor
Figure B-1
SC Dual Fuel
Burners
Primary Fuel
Buttery
Combustion Head
Oil Pressure
Gauge
Figure B-2
SC Burner Side View
Control
Transformer
IgnitionTransformer
Blower Motor
Secondary
Fuel Supply
Primary
Fuel Supply
Gas Separator Solenoid Valve
