22
WeCo Srl Italy www.wecobatteries.com 4K4LT V1.00 24/01/2023
Step 3.a: Lay Lift and place the second battery on top of the first already installed on the floor on its rubber feet.
Step 4: Once each battery has been installed horizontally, the feet supplied with the battery in standard configuration can be removed and
installed through the modules to constrain the modules on both sides.
Each battery weighs about 50 kg and must be installed with the aid of a mechanical lift, and/or with at least two people equipped
with suitable suction cups for lifting or with lifting belts.
At this point you can proceed with the wiring.
