WEG CFW100 series Quick Setup Guide

Quick Setup Guide
CFW100
Mini Drive
J
Commercial dryers
J
Centrifugal pumps
J
Fans/Ventilation
J
Process dosing pumps
J
Blenders/Mixers
OEM Solutions
Mini frequency inverters with integrated micro-PLC
are well suited for simple technical applications in the
commercial sector and OEM users, such as elevators
doors or fitness equipment, as well as small fans,
mixing machines, roller tables and special-purpose
machines for small processes. Combining extensive
functionality with extremely small size, the CFW100 is
easy to integrate into electrical cabinets and many
machines.
Applications
J
Stackers/Palletizers
J
Rotary filters
J
Roller tables
J
Small material handling
applications
Motors | Automation | Energy | Transmission & Distribution | Coatings
Rev: 00 | Date (m/y): 06/2014 The values shown are subject to change without prior notice.
WEG Electric Corp.
6655 Sugarloaf Parkway
Duluth, GA 30097
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com

WEG CFW100 series Specifications

General

Protection Degree	IP20
Frequency	50/60 Hz
Overload Capacity	150% for 60 seconds
Braking	DC braking
Communication	Modbus RTU
Power Range	0.18 to 4 kW
Input Voltage	200-240 V
Output Voltage	0 to 100% of input voltage
Control Type	V/F Scalar Control
Ambient Temperature	-10°C to +50°C
Output Frequency	0 Hz to 400 Hz
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Operating Temperature	-10°C to +50°C
Humidity	5 to 90% non-condensing
Cooling Method	Forced air cooling
