5
M10 x 65mm Bolt (17)
M10 x 85mm Bolt (23)
M10 x 25mm Bolt (25)
M8 x 68mm Bolt (26)
M10 x 63mm Carriage Bolt (18)
M6 Washer (22)
M10 Nylon Locknut (19)
M8 Nylon Locknut (27)
M4 x 16mm Screw (28)
M6 x 16mm Bolt (24)
M6 x 45mm Bolt (16)
M8 x 15mm Bolt (29)
M10 Large Washer (20)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST on page 14. Note: Some small parts may have been
pre-attached. If a part is not in the parts bag, check to see if it has been preattached.
