11. Attach the Curl Pad (12) to the Curl Upright (13)
with two M6 x 16mm Screws (24).
Slide the Curl Upright (13) into the Front Leg (8).
Align one of the adjustment holes in the Curl
Upright with the adjustment hole in the Front Leg.
Tighten the Small Threaded Knob (19) into the
adjustment hole in the Front Leg.
11
12
13
19
8
24
