15. Press a 1 3/4Ó Square Inner Cap (44) into the
lower end of the Left Arm (47). Using a small
amount of soapy water, slide a Foam Arm
Pad (45) onto the Left Arm.
Assemble the Right Arm (48, not shown) in
the same manner.
16. Lubricate both axles on the Top Frame (55).
Slide the Right Arm (48) onto the right axle.
Note: Be careful not to confuse the Right
Arm with the Left Arm (47). Make sure that
the upper end of the Right Arm is behind
the indicated bracket on the Top Frame (55).
Tap two 1Ó Retainers (68) and a 1Ó Round
Outer Cap (65) onto the right axle. Make sure
the teeth on the Retainers bend toward the
Round Outer Cap, as shown in the inset
drawing.
Attach the Left Arm (47) in the same manner.
17. Important: As you assemble the Short
Cable (23) in steps 17Ð22, refer to the
Cable Diagram on page 19.
Route the Short Cable (23) up through the
hole in the Top Frame (55) as shown. Make
sure the ball is on the indicated side. Insert a
ÒVÓ Pulley (6) into the hole in the Top Frame.
Attach the ÒVÓ Pulley using a a 3/8Ó x 3 1/4Ó
Bolt (8), two 3/8Ó Flat Washers (9), two 5/8Ó x
1/2Ó Spacers (82), and a 3/8Ó Nylon Locknut
(21) as shown. Do not overtighten the Nylon
Locknut. The Pulley must be able to turn
freely.
18. Route the Short Cable (23) around another
ÒVÓ Pulley (6). Hold a Long Cable Trap (50)
against the Pulley so that it secures the Short
Cable in the groove of the Pulley.
Attach the Pulley (6) and the Long Cable Trap
(50) to the indicated bracket on the Top
Frame (55) using a 3/8Ó x 2 1/4Ó Bolt (76) and
a 3/8Ó Nylon Jamnut (67). Do not overtight-
en the Nylon Jamnut. The Pulley must be
able to turn freely.
