Weider 245 - Page 12

26
23
24
25
23. Important: As you assemble the Long
Cable (23) in steps 23Ð30, refer to the
Cable Diagram on page 19.
Route the Long Cable (69) as shown between
the Base (4) and the Press Frame (17). Lay
the Long Cable in the bracket on the Base.
Attach the Pro-Pulley (77) to the bracket
using a 3/8Ó x 2Ó Bolt (12) and a 3/8Ó Nylon
Locknut (21). Do not overtighten the Nylon
Locknut. The Pulley must be able to turn
freely.
24. Hold the Long Cable (69) against a 3 1/2Ó
Pulley (15). Hold a Cable Trap (66) against
the Pulley to hold the Cable in place.
Attach the 3 1/2Ó Pulley (15) and the Cable
Trap (66) to the Front Upright (42) as indicat-
ed, using a 3/8Ó x 4 1/4Ó Bolt (64), a 3/8Ó Flat
Washer (9), and a 3/8Ó Nylon Locknut (21).
Do not overtighten the Nylon Locknut. The
Pulley must be able to turn freely.
25. Remove the pre-assembled 3 1/2Ó Pulleys
(15) from the Pulley Plates (58). Route the
Short Cable (23) around one of the Pulleys.
Reattach a Pulley Plate (58) to each side of
the Pulley with a 3/8Ó x 2Ó Bolt (12) and a 3/8Ó
Nylon Locknut (21). Do not tighten the
Nylon Locknut yet.
Route the Long Cable (69) around the other
3 1/2Ó Pulley (15). Attach the Pulley to the
bottom set of holes in the Pulley Plates (58)
with a 3/8Ó x 2Ó Bolt (12) and a 3/8Ó Nylon
Locknut (21). Do not overtighten the Nylon
Locknuts; the Pulleys must be able to turn
freely.
26. Route the Long Cable (69) around a 3 1/2Ó
Pulley (15) as shown. Hold a Cable Trap (66)
against the Pulley so that the Cable is held
securely in the groove.
Attach the 3 1/2Ó Pulley (15) and the Cable
Trap (66) to the Front Upright (42) as shown,
using a 3/8Ó x 4 1/4Ó Bolt (64), a 3/8Ó Flat
Washer (9), and a 3/8Ó Nylon Locknut (21).
Do not overtighten the Nylon Locknut. The
Pulley must be able to turn freely.
12
CABLE ASSEMBLY
69
12
77
21
Bracket
17
4
21
58
21
42
66
69
64
9
69
21
42
9
15
15
23
12
58
69
66
64
15
