18
3
0. Orient the Backrest (11) so that the wide end is
facing downward.
Attach the Backrest (11) to the Upright (5) with
t
wo M8 x 42mm Screws (62) and two M8
Washers (74).
30
31. Orient the Seat (10) so that the wide end is in
the indicated location.
Attach the Seat (10) to the Seat Frame (2) with
four M8 x 16mm Screws (63) and four M8
Washers (74).
31
11
10
63
63
74
74
Wide End
Wide
End
5
2
6
2
62
74
74
To Next Page
