Weider 2990 I - Page 19

19
32. Identify the Long Pad Tube (19) and the Short
Pad Tube (20).
I
nsert the Long Pad Tube (19) through the
bracket on the Seat Frame (2). Slide two Small
F
oam Pads (39) onto the ends of the Long Pad
Tube.
Insert the Short Pad Tube (20) through the Leg
Lever (3). Slide two Small Foam Pads (39) onto
the ends of the Short Pad Tube.
3
2
33. Slide the upper end of a Shroud (29) onto a
Shroud Bracket (30).
Then, slide the lower end of the Shroud (29)
onto a Shroud Bracket (30).
Repeat this step for the other Shroud (29).
33
39
39
39
39
19
20
30
30
30
30
29
29
3
2
