Weider 2990 I - Page 9

9
5. Orient the Upright (5) as shown.
Attach the Upright (5) to the Long Base (1) with
t
wo M10 x 25mm Screws (60) and two M10
Washers (73).
5
5
60
60
73
73
1
6. Orient the Seat Frame (2) as shown.
Attach the Seat Frame (2) and a Base Plate
(83) to the Upright (5) with two M10 x 55mm
Bolts (57), four M10 Washers (73), and two
M10 Locknuts (68).
6
5
57
68
2
68
73
73
83
73
73
