M10 x 155mm Screw (131)
M8 Nylon
Locknut (170)
M6 Nylon
Locknut (156)
M8 Jamnut
(177)
Bracket Retainer (73)
M10 x 100mm Screw (117)
M10 x 110mm Screw (130)
M10 x 30mm Screw (134)
M10 x 60mm Bolt (133)
M10 x 25mm Bolt (166)
M10 x 93mm Bolt (129)
M10 x 55mm Bolt (127)
M10 x 65mm Bolt (137)
M10 x 45mm Bolt (140)
M10 x 90mm Bolt (124)
M10 x 83mm Bolt Set (118)
M10 x 165mm Bolt (123)
M10 x 25mm Screw (128)
M10 x 48mm Bolt (125)
M10 Nylon
Locknut (153)
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts may
have been preattached. If a part is not in the parts bag, check to see if it has been preattached.
PART IDENTIFICATION CHART
