PART LIST—Model No. WESY50200 R1297A
3
BEFORE YOU BEGIN
ASSEMBLED DIMENSIONS:
Height: 78 inches
Base: 35 inches x 86 inches
Weight Stack
Foot Plates
Lat Bar
Low Pulley Station
Thank you for selecting the versatile WEIDER
®
COBRA 1000 HOME GYM SYSTEM. The COBRA
1000 offers a selection of weight stations designed to
develop every major muscle group of the body.
Whether your goal is to tone your body, build dramatic
muscle size and strength, or improve your cardiovas-
cular system, the COBRA 1000 will help you to
achieve the specific results you want.
For your benefit, read this manual carefully before
using the COBRA 1000. If you have additional ques-
tions, please call our Customer Service Department at
0345-089009. To help us assist you, please note the
product model and serial number before calling. The
model number is WESY50200. The serial number can
be found on a decal attached to the COBRA 1000 (see
the front cover of this manual).
Before reading further, please review the drawing
below and familiarise yourself with the parts that are
labelled.
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice.
Key No. Qty. Description
1 14 5/16” Nylon Locknut
2 4 3/8” Nylon Locknut
3 2 3/8” Washer
4 3 3 1/2” Pulley
5 7 5/16” Nylon Jam Nut
6 4 Handgrip
7 1 Press Arm
8 1 Press Arm Lever
9 2 Pulley Bracket
10 1 1 1/2” Square Bushing
11 1 Long Lock Pin
12 1 3/8” x 2 3/4” Bolt
13 2 17/32” Long Spacer
14 1 Short “L”–Pin
15 1 4 1/2” Pulley
16 1 Cable Trap
17 1 3/8” x 4” Bolt
18 1 Long Cable
19 1 3/4” Spacer
20 16 5/16” Washer
21 2 5/16” x 1 1/2” Bolt
22 2 3/8” x 1 3/4” Bolt
23 1 5/16” x 2 1/4” Bolt
24 1 Lat Bar
25 4 1/4” x 1/2” Screw
26 2 Backrest Bracket
27 1 Backrest
28 1 Backrest Frame
29 6 5/16” x 2 3/4” Bolt
30 2 Leg Lever Bracket
31 1 Front Leg
32 2 7” Foam Pad
33 4 5 3/4” Foam Pad
34 2 Pad Tube
35 6 3/4” Round Inner Cap
36 6 2” Square Inner Cap
37 1 Leg Lever
Key No. Qty. Description
38 2 Weight Guide
39 2 1/4” x 2 1/2” Carriage Bolt
40 1 Long Pad Tube
41 3 5/16” x 2 1/2” Bolt
42 1 Top Frame
43 2 1” Washer
44 2 2” Square Outer Cap
45 1 Base
46 1 Left Stabiliser
47 1 Right Stabiliser
48 6 5/16” x 2” Bolt
49 2 Foot Plate
50 2 1 1/2” Square Inner Cap
51 10 Weight
52 1 Base Stabiliser
53 1 Weight Guide Top
54 1 Weight Tube
55 1 Weight Tube Guide
56 2 Weight Bumper
57 2 Weight Guide Sleeve
58 1 Long “L”–Pin
59 1 Weight Tube Endcap
60 4 1/4” Nylon Locknut
61 2 1/4” x 1 1/2” Bolt
62 1 5/16” x 3 3/4” Bolt
63 1 Weight Pin
64 2 1/4” Fender Washer
65 1 Leg Lever Bumper
66 1 #8 x 3/4” Self-tapping Screw
67 1 Short Lock Pin
68 1 Medium Cable
69 2 5/16” x 3” Bolt
70 1 Ankle Strap
71 1 Short Cable
72 1 Cable Clip
# 1 User’s Manual
Leg Lever
Press Arm
High Pulley Station
Backrest
