CABLE DIAGRAM
The cable diagram shows the proper routing of the
Long Cable (80). Use the diagram to make sure that
the cable and the cable traps have been assembled
correctly. If the cable has not been correctly routed,
the weight system will not function properly and dam-
age may occur. The numbers show the correct route
for the cable. Make sure that the cable traps do
not touch or bind the cable.
7
4
5
6
1
2
Long Cable (80)
3
17
