Weider PLATINUM 600 - Page 7

7
2. Attach the Upright (3) to the Base (1) with two
3/8” x 2 3/4” Carriage Bolts (88), two 3/8” x 3”
Bolts (87), and four 3/8” Nylon Locknuts (73) as
shown.
Note: This step will be easier to com-
plete if the Upright and Base are tipped on
their sides.
2
1
3. Attach the Foot Plate (4) to the Upright (3) with
three 3/8” x 2 3/4” Carriage Bolts (88), three 3/8”
SAE Washers (75), and three 3/8” Nylon
Locknuts (73).
3
87
73
73
73
3
88
88
75
75
73
73
4
3
