This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the key number of the part, from the PART LIST.
Important: Some parts may have been
pre-assembled for shipping purposes. If you cannot find a part in the parts bags, check to see if it has
been pre-assembled. If a part is missing, call toll-free 1-877-992-5999.
M6 Washer (22)
M10 Nylon Locknut (31)
M10 x 142mm Bolt (23)
M10 x 60mm Bolt (25)
M10 x 68mm Bolt (27)
M10 x 66mm Bolt (28)
M6 x 16mm Screw (24)
M6 x 38mm Screw (32)
M10 x 19mm Screw (5)
M10 Washer (30)
PART IDENTIFICATION CHART
