Weider Pro 4900 Weight Exerciser - Cable Diagrams

Right Stack Cable (68)
Length: 7 feet 7 inches
CABLE DIAGRAMS
The cable diagrams below show the proper routing of the Right Stack Cable (68), the Press Cable (69), the Leg
Lever Cable (70), the Lat Cable (71), and the Ab Cable (72). Use the diagram to make sure that the cables and
the cable traps have been assembled correctly. If the cables have not been correctly routed, the weight bench
will not function properly and damage may occur. The numbers show the correct route for each cable.
Make
s
ure that the cable traps do not touch or bind the cables.
