M10 x 75mm Bolt (133)
M
M8 x 77mm Bolt (94)
M8 x 20mm Shoulder Bolt (88)
M6 x 16mm Screw (85)
M6 x 22mm Bolt (109)
M8 x 72mm Carriage Bolt (84)
M10 x 103mm Bolt (106)
M10 x 80mm Bolt (111)
M10 x 86mm Bolt (92)
M10 x 134mm Bolt (98)
M10 x 115mm Bolt (100)
M8 x 86mm Shoulder Bolt (86)
M8 x 80mm Bolt (89)
M10 x 107mm Bolt (99)
M
M10 x 83mm Bolt (107)
M10 x 155mm Bolt (130)
M
M6 x 35mm Screw (87)
M4 x 16mm Self-
tapping Screw (113)
PART IDENTIFICATION CHART—Model No. 831.15403.2
S
ee the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST in the center of this manual.
Note: Some small parts may
have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached. If a part
is missing, call toll-free 1-877-992-5999.
