Weider Pro 4900 Weight Exerciser - Page 34

Key No. Qty. Description Key No. Qty. Description
1 1 Right Base
2 1 Left Base
3 1 Rear Base
4
1 Right Upright
5 1 Left Upright
6 1 Rear Upright
7 1 Right Top Frame
8 1 Left Top Frame
9 1 Right Seat Frame
10 1 Left Seat Frame
11 1 Leg Lever
12 1 Leg Press Frame
13 1 Press Frame
14 2 Press Arm
15 1 Front Shroud
16 2 Press Handle
17 1 Right Butterfly Arm
18 1 Left Butterfly Arm
19 1 Pull-up Arm
20 1 Dip Arm
21 1 Dip Assist
22 1 Butterfly Frame
23 1 Foot Plate
24 2 Rear Weight Guide
25 1 Rear Shroud
26 4 Shroud Cover
27 1 Backrest Frame
28 1 Right Backrest
29 2 Seat
30 1 Knee Pad
31 2 Pad Tube
32 4 Small Foam Pad
33 1 Left Backrest
34 2 Top Weight
35 18 Weight
36 1 Long Weight Tube
37 1 Left Upright Plate
38 1 Rear Upright Plate
39 24 90mm Pulley
40 7 “V”-pulley
41 2 115mm Pulley
42 32 Half Finger Guard
43 10 Full Finger Guard
44 2 Lock Pin
45 2 Lock
46
1
Lat Bar
47 2 Handgrip
48 11 Small Cable Trap
49 6
Cable
T
rap
50 1 “U”-bracket
51 2
Pulley Plates
52 1
Double “U”-bracket
53 3 50mm Large Round Inner Cap
54 7
63mm Round Inner Cap
55 11 50mm Round Inner Cap
56 2 Press Arm Cap
57 1 56mm Round Inner Cap
5
8 4 Foam Cap
59 2 Top Arm Bushing
60 1 50mm Outer Cap
61 4 32mm Round Inner Cap
62 2 Dip Arm Cap
63 2 25mm Outer Cap
64 1 Cross Brace
65 4 Weight Bumper
66 2 Weight Tube Bumper
67 1 Dip Assist Latch
68 1 Right Stack Cable
69 1 Press Cable
70 1 Leg Lever Cable
71 1 Lat Cable
72 1 Ab Cable
73 2 40mm x 20mm Inner Cap
74 2 40mm Spacer
75 7 12mm Spacer
76 1 Leg Bumper
77 11 19mm Spacer
78 1 Handle
79 2 Large Foam Pad
80 1 Lock Plate
81 2 Left Base Bushing
82 4 M10 x 38mm Screw
83 1 Leg Pin
84 10 M8 x 72mm Carriage Bolt
85 18 M6 x 16mm Screw
86 1 M8 x 86mm Shoulder Bolt
87 1 M6 x 35mm Screw
88 2 M8 x 20mm Shoulder Bolt
89 8 M8 x 80mm Bolt
90 3 M10 x 60mm Bolt
91 2 M8 x 70mm Bolt
92 2 M10 x 86mm Bolt
93 2 Bottom Arm Bushing
94 11 M8 x 77mm Bolt
95 2 Quarter Guard
96 5 M10 x 65mm Bolt
97 5 M8 x 67mm Bolt
98 1 M10 x 134mm Bolt
99 6 M10 x 107mm Bolt
100
1
M10 x 115mm Bolt
101 6 M10 x 45mm Bolt
102 5 M10 x 48mm Bolt
103
3
Cable Clip
104 1 M10 x 72mm Bolt
105
2
M10 x 45mm Button Bolt
106
1
M10 x 103mm Bolt
107 1 M10 x 83mm Bolt
108
3
M10 x 229mm Bolt
PART LIST—Model No. 831.15403.2 R0805A
