Weider Pro 4900 Weight Exerciser - Page 7

7
5. Attach the Rear Upright (6) to the Rear Base (3)
with the two indicated M8 x 72mm Carriage Bolts
(
84) and two M8 Nylon Locknuts (115). D
o not
tighten the Locknuts yet.
6. Attach the Right Upright (4) to the Right Base (1)
with the two indicated M8 x 72mm Carriage Bolts
(84) and two M8 Nylon Locknuts (115). Do not
tighten the Locknuts yet.
5
6
6
4
115
115
3
84
1
15
84
1
