Weider Pro 550 Bench - Attaching the Lat Bar; Storing the Weight Bench

14
STORING THE WEIGHT BENCH
Set the Backrest (22) and the Adjustment Tube (9)
to the position shown (see ADJUSTING THE
BACKREST on page 12), and store the Lat Tower
(14, see STORING THE CURL POST on page 13).
Remove the Indicated Adujustment Knob (56) and
lift the Frame (8) to the vertical position. Then,
insert the Adjustment Knob into the indicated hole.
ATTACHING THE LAT BAR
A
ttach the Lat Bar (33) to the Cable (73) with the
Weight Clip (74).
33
73
74
14
22
56
9
8
