Weider PRO 5500 - PART IDENTIFICATION CHART

M10 Nylon
Locknut (77)
M8 Washer (103)
M8 Nylon
Locknut (78)
M6 Washer
(114)
O
M4 Washer
(104)
M6 Nylon
Locknut (107)
M4 x 12mm
Self-tapping
Screw (102)
M4 x 16mm
Self-tapping
Screw (110)
M6 x 16mm
Screw (88)
M8 x 22mm
Shoulder Bolt (90)
M10 x 75mm Button Screw (118)
90mm Spacer (59)
56.5mm Spacer (69)
21mm Steel Spacer (108)
19mm Spacer (67)
13mm Steel Spacer (109)
11mm Spacer (99)
M10 Washer (80)
M10 Large Washer (105)
M12 Large Washer (98)
M10 x 70mm Bolt (113)
M12 Nut (112)
PART IDENTIFICATION CHART—Model No. WEEVSY2996.0 R0706A
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been preattached. If a part is not in the parts bag, check to see if it has been preattached.
