19. Using a 3/8Ó x 3 1/2Ó Bolt (16), a 3/8Ó Flat
Washer (9), and a 3/8Ó Nylon Locknut (21),
secure a 3 1/2Ó Pulley (15) and a Cable Trap
(66) to the upper hole in the Press Frame
(17). Make sure that the Cable Trap and the
Pulley are oriented as shown.
Hold a 3 1/2Ó Pulley (15) inside the indicated
bracket on the Press Frame (17). Using a 3/8Ó
x 8Ó Bolt (59), two 3/8Ó Flat Washers (9), and
a 3/8Ó Nylon Locknut (21), attach the Pulley to
the Press Frame as shown.
20. Slide a Cable Trap (66) and a 3 1/2Ó Pulley
(15) onto a 3/8Ó x 3 3/4Ó Bolt (71). Insert the
Bolt into the indicated hole in the Front
Upright (42) from the direction shown. Hand
tighten a 3/8Ó Nylon Locknut (21) with a 3/8Ó
Flat Washer (9) onto the Bolt. Be sure that
all parts are oriented as shown. Do not
tighten the Nylon Locknut yet.
21. Slide a Cable Trap (66) and a 3 1/2Ó Pulley
(15) onto a 3/8Ó x 3 3/4Ó Bolt (71). Insert the
Bolt into the indicated hole in the Front
Upright (42) from the direction shown. Hand
tighten a 3/8Ó Nylon Locknut (21) with a 3/8Ó
Flat Washer (9) onto the Bolt. Be sure that
all parts are oriented as shown. Do not
tighten the Nylon Locknut yet.
21
19
15
15
59
16
21
21
66
17
Bracket
66
42
20
11
71
15
9
9
9
21
66
42
71
15
9
21
CABLE ASSEMBLY
