5. Press the Weight Tube Bumper (64) into the
end of the Weight Tube (63). Lubricate the
insides of the holes in the Top Weight (76).
Insert the Weight Tube into the stack of
Weights (25).
Insert both Weight Guides (62) into the stack
of Weights (25). Be sure that the indicated
holes in the Weight Guides are at the top.
6. Attach the upper ends of the Weight Guides
(62) to the Top Frame (55) with the 5/16Ó x 6Ó
Bolt (60), two 1/2Ó x 3/4Ó Spacers (61), and a
5/16Ó Nylon Locknut (3).
7. Press a 1Ó x 7/8Ó Plastic Bushing (75) onto
each welded spacer on the Press Frame (17).
Slide the Press Frame into place on the Base
(4). Note: This will be a tight fit. The
Plastic Bushings should fit on each end of
the indicated tube in the Base. Be sure
that the Press Frame is oriented as shown.
Lubricate the 3/8Ó x 8Ó Bolt (59). Attach the
Press Frame (17) to the Base (4) with the
3/8Ó x 8Ó Bolt and a 3/8Ó Nylon Locknut (21).
7
5
62
Holes
Lubricate
76
63
64
61
55
3
60
17
85
59
75
21
4
Tube
62
6
FRAME ASSEMBLY
7
ARM ASSEMBLY
25
Lubricate
Welded
Spacers
To Next Page
