PART IDENTIFICATION CHART
This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the key number of the part. The second number refers to the quantity needed for assembly.
Important: Some parts may have been pre-assembled for shipping purposes. If you cannot find a part in
the parts bags, check to see if it has been pre-assembled.
M8 Nylon Locknut (4)Ð18
M6 Washer (16)Ð2
M8 Washer (13)Ð7
M10 Nylon Locknut (2)Ð6
M10 Washer (10)Ð2
M10 x 175mm Bolt (7)Ð1
M10 x 43mm Bolt (11)Ð1
M10 x 89mm Bolt (9)Ð2
M10 x 120mm Bolt (12)Ð1
M8 x 68mm Bolt (8)Ð10
1/2" x 1 1/8" Spacer (47)Ð2
M6 x 36mm Screw (6)Ð4
M6 x 62mm Screw (17)Ð1
M6 x 60mm Carriage Bolt (14)Ð1
M8 x 60mm Carriage Bolt (3)Ð10
M6 x 16mm Screw (5)Ð2
M6 Nylon Locknut (15)Ð1
M10 x 72mm Bolt (1)Ð1
MUSCLE CHART
A. Sternomastoid (neck)
B. Pectoralis Major (chest)
C. Biceps (front of arm)
D. Obliques (waist)
E. Brachioradials (forearm)
F. Hip Flexors (upper thigh)
G. Abductor (outer thigh)
H. Quadriceps (front of thigh)
I. Sartorius (front of thigh)
J. Tibialis Anterior (front of calf)
K. Soleus (front of calf)
L. Rectus Abdominus (stomach)
M. Adductor (inner thigh)
N. Trapezius (upper back)
O. Rhomboideus (upper back)
P. Deltoid (shoulder)
Q. Triceps (back of arm)
R. Latissimus Dorsi (mid back)
S. Spinae Erectors (lower back)
T. Gluteus Medius (hip)
U. Gluteus Maximus (buttocks)
V. Hamstring (back of leg)
W. Gastrocnemius (back of calf)
