5
M10 x 180mm Bolt (54)–1
M10 Washer (35)–29
M
M10 x 20mm
Screw (34)–18
M10 x 90mm Carriage Bolt (55)–2
M10 x 100mm Bolt (38)–2
M10 x 195mm Bolt (43)–1
M10 x 110mm Bolt (44)–2
M10 x 65mm Carriage Bolt (40)–2
M10 Locknut
(37)–10
M10 x 73mm Bolt Set (45)–1
M6 x 16mm
Screw (39)–6
M6 x 40mm Screw (41)–4
M10 x 65mm Screw (36)–1
M6 Washer (42)–4
PART IDENTIFICATION CHART
S
ee the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. Note: If a part is not in the hard-
ware kit, check to see if it has been preattached. To avoid damaging parts, do not use power tools for
assembly.
