Operating the Printer
46
1168670000/02/08.11
Control panel
The control panel consists of three LEDs and three multi-purpose buttons.
LEDs
The LEDs show the printer status.
READY Illuminated Normal status of printer
Illuminated Normal status of printer
Flashing together with the
READY LED
The label roll is finished
MEDIA
Flashing PAUSE status
Illuminated Normal status of printer
Off Direct thermal print (ribbon is not inserted)
RIBBON
Flashing together with the
READY LED
The ribbon roll is finished
Table 2 LEDs
Multi-purpose buttons
The printer can either be in a normal (ready) state or in a system state.
Normal mode System mode
PAUSE Interrupt the print job
Resume the print job after interruption
Self-test
FEED Feed in one label Calibrate label sensor
CANCEL Cancel the print job
Continue printing after error has been fixed
Reset
Table 3 Multi-purpose buttons
