7 Earthingandshielding | Potential ratios
53Manual u-control2604080000/03/08.2020
FEFEFEFEFEFEFE
PE
DIN rail
DI/AI DI/AIDO/AO PF-O PF-IDO/AO
earthing concept: The spring contacts underneath the components snap into the DIN rail to make a connection.
