weinor BiConnect BiRec On/Off User Manual

BiConnect BiRec On/ Off
Version 1
2016-01-01
Assembly and installation instructions/ Notice de montage et d’installation
Item number/
We reserve the right to make technical changes/ Sous reserve de modifications techniques
Numéro d’article
119759-0000
Page 8/20
6 Programming
6.1 Programming the remote-receiver BiRec On/Off
The system is supplied pre-programmed as a general rule. This means that, when the
system is delivered, all the components can be controlled using the hand transmitter
supplied. On rare occasions or if servicing has been carried out, however, the system will
need to be programmed on site. This is done by pairing up the hand transmitter and
remote receiver and setting them to various functions.
The mixed operation of bidirectional and unidirectional dispatchers is not possible.
The purpose of programming is the programming of one or more dispatchers on the
BiRec On/Off. With the programming of the first dispatcher, the remote operating mode of the
BiRec On/Off is defined at bidirectional operation or unidirectional operation - according to the
programmed dispatcher.
1. Plug the device into a power socket. The BiRec On/Off is placed in learning mode for 5
minutes.
2. If the BiRec On/Off receives the radio signal of an activated program button P (or learning
key P) within these 5 minutes, the BiRec On/Off is placed in learning mode for 2 minutes. In
learning modes, the BiRec On/Off changes its switching status (OFF / ON) in 3-second
cycles. There is a one second pause between the switching states. The learning sequence
starts with the switching status ON.
6.2 Programming of hand / wall transmitters
The BiRec On/Off does not react to manual central channel commands.
For the programming of hand / wall transmitters, the switching status (ON / OFF) can be learnt in
free allocation to UP / DOWN commands of the sensors.
1. Programming the switching status ON:
By single activation of the UP or DOWN button, define alerts during fast flashing of the
control lamp.
2. Programming the switching status OFF:
By single activation of the UP or DOWN button, define alerts during slow flashing of the
control lamp.
The programming procedure is completed.
If several dispatchers from the hand and wall transmitter group are programmed on the BiRec
On/Off, the last dispatcher to be programmed defines the allocation of all dispatchers within this
group.
