weinor BiConnect BiRec On/Off User Manual

BiConnect BiRec On/ Off
Version 1
2016-01-01
Assembly and installation instructions/ Notice de montage et d’installation
Item number/
We reserve the right to make technical changes/ Sous reserve de modifications techniques
Numéro d’article
119759-0000
Page 9/20
6.3 Programming sensors
In relation to the allocation of the switching states, wind sensors have a higher priority
than light sensors.
For the programming of sensors (sensor transmitters), the switching status (ON / OFF) can be
learnt in free allocation to UP / DOWN positioning commands of the BiRec On/Off.
1. Programming the switching status ON:
By single activation of the UP or DOWN button, define alerts during fast flashing of the
control lamp.
2. Programming the switching status OFF:
By single activation of the UP or DOWN button, define alerts during slow flashing of the
control lamp.
The programming procedure is completed.
If several sensors are programmed on the BiRec On/Off, the last sensor to be programmed
defines the allocation of all sensors within the sensor transmitter group.
6.4 Deleting the BiRec On/Off remote-receiver
To delete individual dispatchers from the
receiver
Hold down the STOP key and LEARN key (1)
at the same time for approx. 10 sec.
To delete all dispatchers from the receiver
(default setting)
Hold down the STOP key as well as the
LEARN key (1), UP and DOWN keys at the
same time for approx. 10 sec.
7
Technical data
Operating voltage/
(Supply voltage)
198 – 253 V/Hz / 50 – 60 V/Hz
Power consumption
< 0.5 (stand by) W
Switching capacity
max. 2000 VA
Radio frequency
868 MHz
Transmission capacity
10 mW
Range
up to 100 m (free field)
approx. 30 m (in buildings)
Permissible ambient temperature
0 – 55°C
Dimensions (L x W x H)
110 x 60 x 40 mm (without plug connector)
Weight
200 g
IP code
IP 20
