Part Number: 2A33687
Release Date: 8/27/2015
Revision: B
21
BOM Table:
BOM ID QTY
PART
NUMBER DESCRIPTION
1 1 P25003 LIFTING EYE
2 1 2P33647 CYLINDER
3 1 2P33754 HEX NUT
4 1 2P33645 BUMPER
5 4 P21181 SHCS
6 1 2P39369 HARD STOP
7 1 2P33855 PISTON
8 1 P23334 SEAL
9 1 P23303 SEAL
10 1 2P37763 SPACER
11 1 P23304 SEAL
12 1 P23333 SEAL
13 10 P23863 SHCS
14 2 P29106 BREATHER VENT
15 1 2P33674 FLANGE
16 1 P33637 PACKING ASSEMBLY
17 1 P33757 ROD WIPER
18 1 2P39529 PACKING NUT
19 1 P16637 SEAL
20 1 2P39526 ROD
21 1 3P23880 GATE
22 1 P23879 SPRING
23 1 4P23875 BUSHING
24 1 P23878 PIN
25 1 2P39528 SPIDER
26 1 3P24314 NOZZLE ASSEMBLY
27 1 P28822 SEAL
28 1 4P10258 SEAL RING
29 1 P10261 RETAINER RING
30 3 3P10260 RETAINER SEGMENT
31 1 2P10257 WING NUT
32 1 P33001 CLEVIS PIN
33 1 2P40168 RETAINER SPRING
34 3 P23017 DOWEL PIN
35 4 P24708 SHSS
36 1 2P39527 BODY
