2. Adjust the test choke, engine, and transmission according to the values below. These settings
should be approximately as follows:
PLUNGER
DIAMETER
IN (MM)
INPUT SPEED
PINION PUMP
RPM
POWER
BHP KW
PRESSURE
PSI MPA
FLOW RATE
GPM BPM LPM
2 1/2 (63.5)
1105 240
305 227.4
5129 35.4 92 2.2 347
2 3/4 (69.9) 331 247.0
4604 31.7 111 2.6 420
3 (76.2) 360 268.5
4204 29.0 132 3.1 500
3 1/2 (88.9)
380 283.4
3261 22.5 180 4.3 680
4 (101.6)
2496 17.2 235 5.6 889
4 1/2 (114.3)
1972 13.6 297 7.1 1125
Run the plunger pump at this setting for one hour. During this time, closely observe the plunger
pump for any unusual noise, vibration, fluid leaks, and oil leaks. Record all pertinent information
such as elapsed time, ambient temperature, power end lube oil temperature, power end lube oil
pressure, supercharge pressure, etc. After returning the engine to idle and the transmission to
neutral, physically inspect the plunger pump before proceeding further.
3. Adjust the test choke, engine, and transmission according to the values below. These settings
should be approximately as follows:
PLUNGER
DIAMETER
IN (MM)
INPUT SPEED
PINION PUMP
RPM
POWER
BHP KW
PRESSURE
PSI MPA
FLOW RATE
GPM BPM LPM
2 1/2 (63.5)
811 176
340 253.5
7795 53.7 67 1.6 255
2 3/4 (69.9) 392 292.7
7437 51.3 81 1.9 308
3 (76.2) 450 335.6
7164 49.4 97 2.3 367
3 1/2 (88.9)
490 365.4
5731 39.5
132 3.1 499
4 (101.6) 4388 30.3
172 4.1 652
4 1/2 (114.3) 3467 23.9
218 5.2 825
