Weishaupt WCM-FS 2.0 User Manual

6 Operation
6.1 Operating panel WCM-FS 2.0
control
modul
1 Dial knob Navigation through levels and parameters,
change values,
switch on illumination.
2
Function keys 1 … 4 Used to activate functions.
3
Presence and absence key Used for short term interruption or extension of
the heating program.
Used to set duration of effectiveness.
4
Menu key Used to activate or exit end user level.
Used to access or exit heating engineer level.
Installation and operating instruction
Remote control station WCM-FS 2.0 and extension module WCM-EM 2.1
6 Operation
83277502 • 3/2012-10 • La
25-106
