Activate heating engineer level (see Ch. 6.5).

▶

Press function key

DHW

✓

DHW

is displayed.

▶

Press function key

Legio Fct

✓

Parameter

Legio Fct

is displayed.

▶

Make selection using the dial knob and save with function key

DHW

Legio Fct

Antileg setpoint temp 60.0°C

End

DHW maximum 60.0°C

Legio Fct 605

End

Solar

Standard

Friday

Solar utilisation

Installation and operating instruction

Remote control station WCM-FS 2.0 and extension module WCM-EM 2.1

6 Operation

83277502 • 3/2012-10 • La

86-106

Table of Contents2
User Instructions5
User Guide5
Symbols5
Target Group5
Guarantee and Liability5
Safety6
Permissible Application6
Safety Measures6
Electrical Connection6
Disposal6
Product Description7
Type Key7
Variations8
Control with One Pump Heating Circuit8
Control of Multiple Heating Circuits9
Control with 2 Separate Heating Circuits in One Room10
DHW Preparation Via WCM-EM11
Control Via Control Centre12
Independent Control with WCM-FS und WCM-EM13
Technical Data14
Electrical Data14
Approval Data14
Ambient Conditions14
Compatibility15
Installation16
Wcm-Fs16
Wcm-Em18
Electrical Installation19
Wcm-Fs19
Wcm-Em20
Open Housing Cover20
Connect WCM-EM20
Connecting WCM-EM to Condensing Boiler22
Wiring Diagram WCM-EM as Heating Circuit Controller23
Wiring Diagram WCM-EM as DHW Load Circuit24
Connecting the Pump Shut off Set to the WCM-EM24
Operation25
Operating Panel WCM-FS 2.025
Standard Display26
Operating Display of the WCM-EM27
End User Level28
Menu Structure End User Level30
Heating Engineer Level32
Menu Structure Heating Engineer Level34
Menu Structure Heating Engineer Level DHW39
Menu Structure Heating Engineer Level Control Centre40
Setting the Language42
Configuration of the WTC Heat Exchanger43
Configuration WCM-EM44
Set Heating Circuit Type#145
Set Control Variable#147
Retrieving System Information48
Set Function of Variable Input H150
Test Heating Circuit/Dhw Outputs51
Set External Sensor Correction on WCM-EM52
Set Minimum Supply Temperature53
Set Maximum Supply Temperature54
Set Priority of DHW Loading55
Set Boiler Mixer Circuit Boost56
Set Mixer Parameters57
Set Frost Protection58
Set Minimum Pump Speed59
Set Maximum Pump Speed60
Set Speed Variables61
Set WTC Delay62
SOL Yield HC63
Set Screed Program65
Function Specific Heating70
Screed Heating72
Set Night Setback Operation74
Set Frost Limit75
Set Switch on Optimisation76
Set Type of Building77
Set Room Thermostat#178
Set Adaption#179
Set Room Factor-P80
Set Maximum DHW Temperature81
Set DHW Switch Differential82
Set DHW Boost83
Set Maximum DHW Load Time84
Set Legionella Protection Function85
Set Antilegionella Setpoint Temperature87
Set Legionella Time88
Activate Circulation During Legionella Protection Function89
Set Circulation Time90
Set Circulation Return Temperature91
SOL Yield DHW92
Central Control Via Control Centre93
Extension Module Menu Structure95
Extension Module EM-HC (Access HC Without FS)95
Extension Module EM-DHW (Access HC Without FS)96
Reset WCM-EM97
Reconfiguring WCM-EM for System Alterations97
Emergency Operation WCM-EM97
Reset WCM-FS98
Commissioning99
Prerequisite99
Set Address on WCM-EM99
Steps for Commissioning100
Setting the Language100
Set Address on the WCM-FS101
Troubleshooting102
Error Codes102
Technical Documentation104
Sensor Variables104
Key Word Index105
