Weishaupt WG20-/1-C LN Series - Replacing Coil on Multifunction Assembly

Installation and operating instruction
Gas burner WG20…/1-C LN
9 Servicing
83240802 1/2020-01 La
62-96
9.13 Replacing coil on multifunction assembly
Observe notes on servicing [ch.9.1].
Ensure correct voltage and solenoid number when replacing the solenoid coil.
Undo screw 1.
Remove cap2.
Replace solenoid coil3.
3
2
1
