Gas burner WG20…/1-C LN
13 Spares
83240802 1/2020-01 La
83-96
Pos. Description Order No.
2.01 Motor ECK 04/A-2 230 V / 50 Hz 652 084
2.02 Screw M5 x 12 409 278
2.03 Capacitor set 713 476
2.04 Pressure switch LGW 10 A2 1 - 10 mbar 691 370
2.05 Connection flange for LGW 605 243
2.06 Hose 4.0 x 1.75 190 mm 232 050 24 057
2.07 Hose clamp 7.5 790 218
2.08 Fan wheel TLR-S 160 x 61.6-L-E S1 50Hz 241 210 08 032
2.09 Grub screw M8 x 8 w. an. cutter 420 550
2.10 Air guide 232 210 01 147
2.11 Air damper complete 241 210 02 022
2.12 Bearing for air damper shaft 241 110 02 107
2.13 Shaft air damper - angle drive 241 210 02 057
2.14 Angle drive 241 110 02 062
2.15 Screw 4 x 12 Torx-Plus Remform 409 320
2.16 Manual adjustment 241 050 02 022
2.17 Screw 4 x 30 Torx-Plus Delta PT 409 325
2.18 Frame for actuator 241 210 02 037
2.19 Screw 4 x 30 Torx-Plus Delta PT 409 325
2.20 Lever complete 232 210 02 012
2.21 Air regulator spring 2 241 210 02 072
2.22 Gas butterfly valve
– Natural Gas 232 210 25 010
– Liquid Petroleum Gas 233 210 25 010
2.23 Spring 2 241 400 02 167
2.24 Seal connection channel 232 210 25 087
2.25 Treaded rod complete 232 210 25 012
2.26 Blanking plate valve proving 232 210 26 172
