Installation and operating instruction
Oil burner WL30Z-C
9 Servicing
83297902 3/2019-11 La
77-112
9.16 Replacing the fuse
Observe notes on servicing [ch.9.1].
Unplug connection plug from combustion manager.
Replace fuse(T6,3H, IEC 127-2/5).
1 Replacement fuse
9.17 Set flame senor RAR9 (optional)
Only in conjunction with continuous operation.
Observe notes on servicing [ch.9.1].
Remove flame sensor.
Undo screw1.
Set flame sensor2.
Tighten screw 1.
