14. MMA Welding cable connector. (The adaptor 15 should be connected
to 14 before plugging the MMA welding plug.)
As the following picture show:
ALPHA 225 MMA Welding
68
15. Connection foot pedal (ALPHA 225)
connection foot pedal
ALPHA 225
69
ALPHA 335
Grounding the tool:
Attach a ground wire (not supplied) to the screw in the lower middle of the back of
the tool case. Connect the other end of the wire to an appropriate ground, such as a
steel workbench, steel biding member or grounding electrode.
ASSEMBLY
GROUNDING
SCREW
