Welch Allyn MicroTymp® 4 Tympanometer User Manual
DIR 80024157 Ver A Page 10
Press the down ▼ navigation keys to scroll through the menu until CONFIGURATION is
highlighted and then press the right navigation key ► to select.
CONFIGURATION
The configuration menu contains 17 items with the values and defaults indicated in the table
below. Select and change the items as necessary to set up your device before you begin testing.
The settings are retained in memory after the unit is turned off.
Configuration Item
(Sweep Settings)
Value Options
Default Value
Test Sequence
Both: L, R
Both: R, L
Both: R, L
Ear Seal Check
Standard or Extended
Standard
Reload Defaults
(Sweep Settings)
Yes or No
No
Configuration Item
(Reflex Settings)
Value Options
Default Value
Reflex Levels
100 dB/10 dB Steps
100 dB/5 dB Steps
95 dB/5 dB Steps
90 dB/5 dB Steps
85 dB/5 dB Steps
95 dB/5 dB steps
Reflex Frequencies
500 Hz, 1k, 2k, & 4kHz (individually
selectable)
1 kHz
Reflex Selection
Always Measure
Never Measure
Only If Peak Found
Prompt To Measure
Only if Peak Found
Reflex Threshold
0.01 to 0.5 ml
0.03 (ml)
Reflex Auto Stop
Yes or No
Yes
