Welch Allyn MicroTymp® 4 Tympanometer User Manual
DIR 80024157 Ver A Page 25
SENDING THE RESULTS TO A PRINTER
The MPT-II printer is available as an option for use with the MicroTymp 4. Printing is by a cable
connecting the printer to the instrument cradle. Before attempting to print ensure the printer is
fully charged, switched on, loaded with paper and ready to print. If the MicroTymp 4 is in the
cradle the data will be sent via the connecting cable. This operation is carried out automatically,
although reference should be made to the appropriate guidance notes below.
Connect the printer to the MicroTymp 4 cradle using the supplied cable. With the device located
in the cradle print the required data.
PRINTING RESULTS
To print the results of the last test select SEND TO PRINTER from the PROCESS RESULTS menu on
completion of the test. (Similar facilities for printing are available from the VIEW THE LAST TEST
and DATA MANAGEMENT options in the MAIN MENU.)
The following display is then presented:
PROCESS RESULTS
PRESS KEY WHEN READY
Back Select
Press ► when the printer is ready.
Once the print operation has been carried out the PROCESS RESULTS menu is displayed.
