Welch Allyn MicroTymp® 4 Tympanometer User Manual
DIR 80024157 Ver A Page 23
SAVING RESULTS IN THE DATABASE
To save the results of a test select SAVE RESULTS from the PROCESS RESULTS menu that is
displayed on completion of a test. This option can also be accessed by selecting VIEW THE LAST
TEST from the main menu and scrolling through the results using the ► key as long as the test
results have not already been saved or deleted (e.g. by starting and then aborting a new test).
A three-character identifier is used for the record. This is also used as the reference for the
patient’s name on the printed record and for data transferred to a computer. The identifier
would typically be the patient’s initials, and as the tympanometer uses a combination of this
identifier and the date/time of a test to refer to stored records this same identifier may be used
for different tests for the same patient.
DATA ENTRY
PATIENT INITIALS
________
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
- 0123456789
Hold to Enter / Cancel
To enter the identifier:
 Use the ▲, ▼, ◄ and ► keys to select a character.
 Press and hold the ► key to enter the selected character.
 Press and hold the ◄ key to delete the last character.
To save the test results:
 Enter all three characters for the identifier.
 Press and hold the ► key to save the record.
