4 Technical Data
4.1 Dimensions
The main dimensions are identical for all pump types stated here.
(1)
Gas ballast valve
For type MPC only
(2)
Intake port
Small flange DN 16 KF (hose nozzle DN 8 for fitting. enclosed))
(3)
Pressure port
Hose nozzle DN 8
Fig. 3 Dimensions (type MPC 301 Z)
4.2 Intake Pressure / Pumping Speed – Diagram
Fig. 4 Intake Pressure / Pumping Speed - Diagram
